8266M-PU Wi-Fi Module

8266M-PU Wi-Fi Module
QCA-2066-5
802.11a/b/g/n/ac/ax+BT5.2
2T2R
PCIe/USB
L22 * W30 * H2.2 mm
Contact us for HDK, SDK and EVB
状态:
  • Wi-Fi 6

  • BT5.0 and above

  • QCA

  • 2T2R

  • Select

  • PCIe Interface

Product Name

QCA-2066-5 Wi-Fi Module 8266M-PU

QCA-2066-5

Wi-Fi 6

PCIe/USB

2T2R

BT5.2

L22 * W30 * H2.2 mm





Details Information

Introduction

8266M-PU is a highly integrated single module supporting 2x2 muti-user MIMO 802.11ax Wi-Fi and Bluetooth (BT) Milan.that with WLAN PCI Express network interface controller and USB interface. supporting simultaneous operation on 2.4 GHz and 5 GHz/ 6 GHz, also known as Dual Band Simultaneous(DBS). DBS mode provide up to 3 Gbps data rate(2x2+2x2 11ax DBS).


 Features

General

Support IEEE802.11a/b/g/n/ac/ax .

Supports 2x2 Multi-User Multiple-Input Multiple-Output (MU-MIMO).

Dual Band Simultaneous (DBS), up to 3 Gbps data rate (2x2+2x2 11ax DBS) .  Support Tri-band 2.4 GHz/5 GHz/6 GHz.

20 MHz/40 MHz channel bandwidth for 2.4 GHz and 20MHz/40 MHz/80 MHz/160 MHz channel

bandwidth for 5GHz/6 GHz.

Host Interface

Supports USB.

Bluetooth Features

Compliant with Bluetooth Milan.

Split ACL support for A2DP true stereo.

Dual Mode support: Simultaneous LE and BR/EDR.

Flexible interface SlimbusPCM /I2S for Bluetooth audio.

BT host digital interface: USB



 Applications

OTT/IPTV/DVB/Set-top Box, Tablet PC, Advertising Machine,Intelligent TV, IPC/NVR, Industrial Control Equipment,Car Recorder,Intelligent Doorbell, Intelligent Projector, Virtual Reality, VR/AR, Wireless Storage, Printer, POS Machine, Electronic Scale,Vehicle Front/Rear End, Drone, Robot, HDMI Transmitter,Smart Gateway, Education,Toys, Lighting Lamps, Intelligent Street Light, Intelligent Home Appliances/Home Appliances Instrumentation (Water, Electricity, Gas), Smart City and other Consumer Electronic Products.



 Block Diagram


1680748258855



 Parameters


Model No.

8266M-PU

Main Chipset

QCA-2066-5

Interface

Wi-Fi: PCI-e
BT: Uart/PCM

Wi-Fi Standard

IEEE802.11a/b/g/n/ac/ax+BT5.2

Data Rate

433Mbps

Certification

RoHS

RF Antenna

External Antenna

OS Supported

Android /Linux/ Win CE /iOS /XP/WIN7/WIN10

Operating Frequency

2.4G:2.400GHz~2.497GHz(2.4G ISM Band)

5.8G:4.900GHz~5.845GHz(5.0G ISM Band)

Operating Voltage

3.3V

Dimension

L22 * W30 * H2.2 mm

RF Chain

2T2R

Operating Temperature

-20°C to 70°C

Storage Temperature

-40°C to 85°C



Ordering Information

Part No.

Description

FG8274NPRX-00

QCA-2066-5, a/b/g/n/ac/ax Wi-Fi+BT5.2, 2T2R, 22X30mm, PCIE+ USB
