Product Name

BES2600iWA2 Wi-Fi Module V200A-S

BES2600iWA2

5G Wi-Fi

SDIO3.0

1T1R

12.0x12.0mm

Details Information

 Introduction

V200A-S is a small size and low profile of Wi-Fi + BT Combo module with LGA module, board size is 12*12mm. It can be easily manufactured on SMT process and highly suitable for tablet PC, mobile device and consumer products. It provides SDIO 3.0 interface for Wi-Fi to connect with host processor and high speed UART interface for BT5.3. It also has a PCM interface for audio data transmission with direct link to external audio codec via BT controller.

The Wi-Fi throughput up to 150Mbps in theory by using 802.11n technology.

 Features

General

Operate at 2.4G&5GHz frequency bands.

IEEE standards support: IEEE 802.11a,IEEE 802.11b, IEEE 802.11g, IEEE 802.11n.

Enterprise level security which can apply WPA2/PSK.

Wi-Fi 1T1R allow data rates supporting up to 150 Mbps PHY rates.

Host Interface

SDIO3.0 for Wi-Fi and UART for BT5.3.

PCM interface for audio data transmission via BT controller.

Bluetooth Features

Compatible with Bluetooth v2.1+EDR v5.2 system.

Support BLE4.0, BT5.3 dual mode.

 Applications

OTT/IPTV/DVB/Set-top Box, Tablet PC, Advertising Machine,Intelligent TV, IPC/NVR, Industrial Control Equipment,Car Recorder,Intelligent Doorbell, Intelligent Projector, Virtual Reality, VR/AR, Wireless Storage, Printer, POS Machine, Electronic Scale,Vehicle Front/Rear End, Drone, Robot, HDMI Transmitter,Smart Gateway, Education,Toys, Lighting Lamps, Intelligent Street Light, Intelligent Home Appliances/Home Appliances Instrumentation (Water, Electricity, Gas), Smart City and other Consumer Electronic Products.

 Block Diagram

 Parameters

 Ordering Information
