8124N-P Wi-Fi 5G band 4x4 11ax PCIe Module

8124N-P Wi-Fi Module
QCN9024
5GHz a/n/ac/ax Wi-Fi
PCIE M.2 E-key
4T4R
IPEX
62.4x57mm
Contact us for HDK, SDK and EVB
状态:
  • 2.4G+5G

  • Without BT

  • Select

  • Select

  • Select

  • PCIe Interface

Product Name

8124N-P Wi-Fi Module QCN9024

QCN9024

5G Wi-Fi

PCIe E-key

4T4R
IPEX
62.4x57mm



Details Information

 Inroduction

8124N-P is an 802.11ax Wi-Fi 5G PCIe radio, with 802.11ax technology is a highly integrated wireless local area network (WLAN) system-onchip(SoC) for 5 GHz IEEE802.11ax/ac/n/a applications. The wireless module complies with IEEE 802.11 a/n/ac/ax 4x4 MIMO standard and it can achieve up to a speed of 4804Mbps (4x4 11ax 160Mhz ). The integrated module provides PCIe interface for Wi-Fi.

 Features

General

4x4/160 MHz 11ax PCIe Radio.

Supports 20/40/80/160 MHz in 5 GHz.  Compliant with IEEE 802.11a/n/ac/ax.

Data rates of up to 4804 Mbps for 160 MHz ax Mode

Supports up to 256 simultaneously connected clients

TxBF, MU-MIMO, MU-OFDMA/TxBF, ML, STBC

IEEE 802.11d, h, i, j, k, r, u, v, and w

Four interfaces to external PAs operating in the 5 GHz

WPA/WPA2-Personal/WPA2-Enterprise and WPA3 Personal

2Mbit serial I²C bus EEPROM


Host Interface

Support PCI Express 2-lane-g2 or 1-lane-g3

 Applications

OTT/IPTV/DVB/Set-top Box, Tablet PC, Advertising Machine,Intelligent TV, IPC/NVR, Industrial Control Equipment,Car Recorder,Intelligent Doorbell, Intelligent Projector, Virtual Reality, VR/AR, Wireless Storage, Printer, POS Machine, Electronic Scale,Vehicle Front/Rear End, Drone, Robot, HDMI Transmitter,Smart Gateway, Education,Toys, Lighting Lamps, Intelligent Street Light, Intelligent Home Appliances/Home Appliances Instrumentation (Water, Electricity, Gas), Smart City and other Consumer Electronic Products.

 Block Diagram

1682329810644


 Parameters

Model No.

8124N-P

Main Chipset

QCN9024

Wi-Fi Interface

PCIe E-key

Wi-Fi Standard

IEEE802.11a/n/ac/ax

Data Rate

4804 Mbps

Certification

RoHS,REACH

RF Antenna

External Antenna

OS Supported

Android /Linux/Windows

Operating Frequency

5.15 GHz ~ 5.850 GHz (5 GHz Band)

Operating Voltage

3.3V

Dimension

L x W x H: 62.4 x 57 mm

RF Chain

4T4R

Operating Temperature

0°C to 70°C

-20°C to 70°C(industrial chip)

Storage Temperature

-40°C to 90°C


 Ordering Information

Part No.

Description

PA8124NPXX-00

QCN9024,5GHz a/n/ac/ax Wi-Fi,4T4R,62.4x57mm,PCIE M.2 E-key,IPEX
