2.4G
Without BT
Realtek
1T1R
Select
SDIO Interface
6189M-SEM RTL8189EM-VI-CG
12.5X14mm
6189M-SEM is a highly integrated single-chip 802.11n WLAN network SDIO interface (SDIO 1.1/ 2.0/ 3.0 compliant) module. WLAN baseband implements OFDM with 1T1R path and is compatible with the IEEE 802.11n specification.support 20M/40MHZ bandwidth.provide higher data rates of 54Mbps and 150Mbps for IEEE 802.11g and 802.11n OFDM respectively
Operate at ISM frequency bands (2.4GHz)
Support 20/40MHz Bandwidth, IEEE 802.11b/g/n
Complies with SDIO 1.1/ 2.0/ 3.0 for WLAN with clock rate up to 80MHz
150Mbps PHY rate using 40MHz bandwidth
IEEE 802.11e,i
Model No. | 6189M-SEM | Main Chipset | RTL8189EM-VI-CG |
Interface | Wi-Fi: SDIO | Wi-Fi Standard | IEEE802.11b/g/n+BLE5.0 |
Data Rate | 54Mbps | Certification | RoHS,REACH |
RF Antenna | On-board Antenna | OS Supported | Android/Linux |
Operating Frequency | 2.400～2.4835GHz | Operating Voltage | 3.3V |
Dimension | L14.0 *W12.0 *T2.2mm | RF Chain | 1T1R |
Operating Temperature | -30°C to 85°C | Storage Temperature | -40°C to 85°C |
Ordering Information
Part No. | Description |
FG6189MSEM-V0 | RTL8189EM-VI-CG,b/g/n,Wi-Fi,1T1R,12.5X14mm,SDIO3.0, 邮票孔 |
