R110C-IA Bluetooth Module

R110C-IA Bluetooth Module
LE5010AI
BLE5.0/BLE5.1
UART
with shielding
L18.6 x W13 x H2.5 mm
状态:
  • Select

  • Select

  • Select

Product Name

R110C-IA LE5010AI


LE5010AI
BLE5.0/BLE5.1
UART
with shielding
L18.6 x W13 x H2.5 mm



Details Information

 Introduction

Fn-Link Technology would like to announce a low-cost and low-power consumption BT5.0 module. It is  highly integrated internally with a 32-bit MCU with 64kByte SRAM and 512kByte Flash, as well as bluetooth  5.0 BLE transceiver. The Bluetooth wireless module complies with the Bluetooth 5.0 BLE standard. Moderate  module size. suitable for applications such as smart LEDs. lt can efficiently solve emergency communication  problems in complex environments such as high-rise,underground ,tunnels and large complex environments.


 Features


General

LE Broadcasting Development

Support OTA control escalation

Support UART communication


Bluetooth Features

Support Bluetooth 5.0 LE standard  Supports 2Mbps LE


 Block Diagram

1681874376053


 Parameters

Model No.

R110C-IA

Main Chipset

LE5010AI

BT Interface

UART

BT Standard

BLE5.0/BLE5.1

Data Rate

72.2Mbps

Certification

RoHS

RF Antenna

On-board Antenna

OS Supported

Android /Linux/ Win CE /iOS /XP/WIN7/WIN10

Operating Frequency

2.400~2.4835GHz

Operating Voltage

3.3V

Dimension

L18.6 x W13 x H2.5 mm

RF Chain

/

Operating Temperature

-20°C to 85°C

Storage Temperature

-40°C to 125°C


 Ordering Information

Part No.

Description

FGR110CIAX-00

LE5010AI,BLE5.0/BLE5.1 ,18.6*13mm,UART, with shielding
