5220D-UUQ Wi-Fi6 Module

MT7920QUN 2T2R
802.11a/b/g/n/ac/ax
BT5.2   USB3.0
27.0 x 18.0mm

状态:
  • Wi-Fi 6
  • BT5.0 and above
  • MTK
  • 2T2R
  • Select
  • Wi-Fi&BT Interface

Product Name

MT7920QUN Wi-Fi6 Module  5220D-UUQ

MT7920QUN

802.11a/b/g/n/ac/ax

USB3.0

2T2R

BT5.2

27.0 x 18.0mm



Details Information

Introduction

Fn-Link Technology would like to announce a low-cost and low-power consumption module which has all of the Wi-Fi functionalities.It is a highly-integrated IEEE 802.11 a/b/g/n/ac/ax MAC/Baseband/RF WLAN single chip.For Wireless LAN operation. The integrated module provides USB interface for Wi-Fi.The module provides simple legacy and 20MHz/40MHz/80MHz co-existence mechanism to ensure backward and network compatibility.

The wireless module complies with IEEE 802.11 a/b/g/n/ac/ax 2x2 MIMO standard and the speed can achieve up to 1201Mbps with dual stream in 802.11ax. The integrated module provides USB interface for Wi-Fi, USB/ PCM interface for Bluetooth.

This combo module is a total solution for a combination of Wi-Fi and Bluetooth V5.2 technologies. The module is specifically developed for all portable devices.


Features

General

Highly integrated wireless local area network (WLAN) system-on-chip (SOC) for 802.11a/b/g/n/ac/ax WLAN applications.

Supports Dual band Single concurrent (2.4G/5G).

PHY Features

Dual-stream spatial multiplexing up to 1201 Mbps data rate.

Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz.

Supports Transmit Beamformee.

Host Interface

Supports low power USB3.0(complies with USB2.0) interface for WLAN and USB/PCM interface for Bluetooth.

Bluetooth Features

Supports Bluetooth system (BT5.2 Logo Compliant).

Supports WLAN/Bluetooth coexistence.

Compatible with Bluetooth v2.1+EDR.

Dual Mode support: Simultaneous LE and BR/EDR.

BT host digital interface:

- USB

- PCM for audio data

Applications

OTT/IPTV/DVB/Set-top Box, Tablet PC, Advertising Machine,Intelligent TV, IPC/NVR, Industrial Control Equipment,Car Recorder,Intelligent Doorbell, Intelligent Projector, Virtual Reality, VR/AR, Wireless Storage, Printer, POS Machine, Electronic Scale,Vehicle Front/Rear End, Drone, Robot, HDMI Transmitter,Smart Gateway, Education,Toys, Lighting Lamps, Intelligent Street Light, Intelligent Home Appliances/Home Appliances Instrumentation (Water, Electricity, Gas), Smart City and other Consumer Electronic Products.

Block Diagram

5220D-UUQ  block diagram

Parameters

Model No.

5220D-UUQ

Main Chipset

MT7920QUN

Interface

Wi-Fi: USB V2.0/V3.0

BT: USB / PCM

Wi-Fi Standard

IEEE802.11a/b/g/n/ac/ax+BT5.2

Data Rate

1201Mbps

Certification

RoHS,REACH

RF Antenna

External Antenna

OS Supported

Android /Linux/iOS /WIN10

Operating Frequency

2.4G:2.400GHz~2.497GHz(2.4G ISM Band)

5.8G:4.900GHz~5.845GHz(5.0G ISM Band)

Operating Voltage

3.3V

Dimension

L27.0 * W18.0 * T2.5 mm

RF Chain

2T2R

Operating Temperature

0°C to 70°C

Storage Temperature

-40°C to 85°C


Ordering Information

Part No.

Description

FG5220DUUQ-00

MT7920QUN,a/b/g/n/ac/ax,Wi-Fi+BT5.2,2T2R,USB3.0, 3 Antenna ,with shielding
