8274N-PR Wi-Fi Module

QCA6574A-1 2T2R
PCIe/Uart 5G Wi-Fi
BT5.0 / BLE5.0
23.4 x 19.4mm
状态:
  • 2.4G+5G
  • BT5.0 and above
  • QCA
  • 2T2R
  • Select
  • Wi-Fi&BT Interface

Product Name

QCA6574A-1 Wi-Fi Module 8274N-PR

QCA6574A-1

5G Wi-Fi

PCIe/Uart

2T2R

BT5.0 / BLE5.0

23.4 x 19.4mm




Details Information

Introduction

8274N-PR is a single-die WLAN and BT combo module. support 2×2 MIMO with two spatial streams IEEE802.11 a/b/g/n/ac WLAN standards and Bluetooth 5.0 enabling seamless integration of WLAN/Bluetooth and Low Energy technology. Supports low power PCIe (w/L1 sub-state) interfaces for WLAN and UART/PCM interface for Bluetooth.


Features

General

Highly integrated WLAN SOC for 5 GHZ 802.11ac, or 2.4G/5G 802.11n WLAN applications .

Maximal Likelihood (ML) decoding, Low-Density Parity Check(LDPC), Rx Space Time Block Code (STBC), and 1.5 kb of On Chip One-time Programmable (OTP) memory.

Supports 20 MHz/40 MHz at 2.4 GHz and supports 20 MHz/40MHz/80 MHz at 5 GHz.

Host Interface

Supports Bluetooth-WLAN coexistence and ISM-LTE coexistence.

Bluetooth Features

Supports Bluetooth 5.0, ANT+ and is backward-compatible with previous Bluetooth versions from v1.2 .

BT host digital interface:

- HCI UART (up to 3.2 Mbps)

- PCM for audio data


Applications

OTT/IPTV/DVB/Set-top Box, Tablet PC, Advertising Machine,Intelligent TV, IPC/NVR, Industrial Control Equipment,Car Recorder,Intelligent Doorbell, Intelligent Projector, Virtual Reality, VR/AR, Wireless Storage, Printer, POS Machine, Electronic Scale,Vehicle Front/Rear End, Drone, Robot, HDMI Transmitter,Smart Gateway, Education,Toys, Lighting Lamps, Intelligent Street Light, Intelligent Home Appliances/Home Appliances Instrumentation (Water, Electricity, Gas), Smart City and other Consumer Electronic Products.


Block Diagram

8274n-pr


Parameters

Model No.

8274N-PR

Main Chipset

QCA6574A-1

Interface

Wi-Fi:PCI-e
BT:UART/PCM

Wi-Fi Standard

IEEE802.11a/b/g/n/ac+BLE5.0

Data Rate

433Mbps

Certification

RoHS,REACH

RF Antenna

External Antenna

OS Supported

Android /Linux/ Win CE /iOS /XP/WIN7/WIN10

Operating Frequency

2.4G:2.400GHz~2.497GHz(2.4G ISM Band)

5.8G:4.900GHz~5.845GHz(5.0G ISM Band)


Operating Voltage

3.3V

Dimension

L23.4 * W19.4 * T2.3 mm

RF Chain

2T2R

Operating Temperature

-40°C to 85°C

Storage Temperature

-40°C to 125°C


Ordering Information

Part No.

Description

FG8274NPRX-00

QCA6574A-1, a/b/g/n/ac Wi-Fi+BLE5.0, 2T2R, 23.4X19.4mm,

PCIE+ Uart(Automotive Grade)
